潛望鏡

潛望鏡（Periscope），是一種利用光線反射原理所製作的光學儀器，最常被用在潛水艇用以在水下觀察水面上的動靜。曾在塹壕戰中被用來從壕溝觀察敵軍動態。潛望鏡並非只有軍事用途，過往雙層巴士亦有裝置潛望鏡，讓坐在下層的司機可觀察上層的情況，雙層巴士的潛望鏡至2000年代才逐漸由閉路電視取代[1]。

Military handheld periscope optical design.
1 - Eyepiece
2 - Diagonal prism
3 - Handle
4 - 6 - Erecting lenses
5 - Periscope tube
7 - Field lens
8 - Lens
9 - Head diagonal prism
10 - Window
潛望鏡示意圖
Principle of the periscope.
A - Periscope using two plane mirrors.
B - Periscope using two right–angled prisms.
1 - 2 - Plane mirrors.
3 - 4 - Right–angled prisms.
5 - 6 - Observer eye.
7 - 8 - Periscope tube.
H - Periscope optical height.
Principle of the lens periscope.
A - Periscope using a single lens (L2) to correct image.
B - Periscope which uses two lenses (L2-L3) to correct image.
1-3 - Periscope window.
2-4 - Field stop or reticle.
P - Right–angled prisms (or plane mirrors).
L1 - Objective lens.
L2 - for A - L2 - L3 - for B - Image erecting lens.
L3 - L4 -for A - L4-L5- for B - Eyepiece.
L0 - Field lens.
y - Distant object.
H - Periscope optical height.
  • Submarine monocular attack periscope.
    Submarine monocular attack periscope.
  • Zeiss submarine periscope optical design.
    Zeiss submarine periscope optical design.


圖片
海軍使用潛望鏡
  • Officer at periscope in control room of a U.S. Navy submarine in World War II. The officer pictured is Captain Raymond W. Alexander, Sr. and the photo was taken in 1942.
    Officer at periscope in control room of a U.S. Navy submarine in World War II. The officer pictured is Captain Raymond W. Alexander, Sr. and the photo was taken in 1942.
  • Submarine monocular attack periscope
    Submarine monocular attack periscope
  • Torpedoed Japanese destroyer Yamakaze（英语：） photographed through periscope of USS Nautilus( USS Nautilus (SS-168)), 25 June 1942.
    Torpedoed Japanese destroyer Yamakaze photographed through periscope of USS Nautilus( USS Nautilus (SS-168)), 25 June 1942.
